0Cr15Al5 FeCrAl Wire for Efficient Electrolysis in Hydrogen Production

0Cr15Al5 FeCrAl Wire for Efficient Electrolysis in Hydrogen Production

Nombre De La Marca:	DLX
Número De Modelo:	Alambre de aleación FeCrAl 0Cr15Al5
Cuota De Producción:	10 kilos
Condiciones De Pago:	LC, D/A, D/P, T/T, Unión Occidental
Capacidad De Suministro:	500 toneladas por mes

Información detallada

Descripción de producto

Información detallada

Lugar de origen:

China, Jiangsu

Certificación:

Ce,Rohs

Capacidad de la fuente:

500 toneladas por mes

Resaltar:

FeCrAl resistance wire for hydrogen production

0Cr15Al5 electrolysis wire

high-efficiency FeCrAl resistance wire

Descripción de producto

0Cr15Al5 FeCrAl Wire for Efficient Electrolysis in Hydrogen Production

As the demand for green hydrogen accelerates, the need for efficient and reliable electrolysis systems has never been greater. At the heart of these systems lies 0Cr15Al5 FeCrAl Alloy Wire, a high-performance material designed to maximize the efficiency of hydrogen production through water electrolysis. This alloy wire, composed of a carefully balanced mix of iron, chromium, and aluminum, offers exceptional durability, corrosion resistance, and thermal stability, making it an essential component in modern electrolysis applications.

The 0Cr15Al5 FeCrAl Wire excels in harsh electrolytic environments, where it is exposed to extreme temperatures and aggressive electrolytes. Whether used in alkaline or high-temperature electrolysis, this wire ensures optimal performance, longevity, and cost-effectiveness, enabling industries to scale up hydrogen production in a sustainable manner.

Parameter Comparison Table

Alloy Nomenclature Performance	1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Chemical Composition (%) - Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
Re	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune
Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
Max. Continuous service temp. of element	950	1250	1250	1250	1100	1350	1400
Resistivity at 20°C (μΩ.m)	1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density (g/cm³)	7.4	7.1	7.16	7.25	7.35	7.1	7.1
Tensile Strength (N/mm²)	580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at rupture (%)	>16	>12	>12	>12	>12	>12	>10

Available Shapes and Sizes

Shape	Size (mm)
Wire	0.05-7.5
Rod	8-50
Ribbon	(0.05-0.35)×(0.5-6.0)
Strip	(0.5-2.5)×(5-180)

Key Features of 0Cr15Al5 FeCrAl Wire

Outstanding Corrosion Resistance: Engineered for resistance to oxidation and corrosion, even in harsh environments involving highly alkaline or acidic electrolytes, ensuring prolonged service life and minimal maintenance requirements.
High-Temperature Performance: With a melting point of 1,420°C, the alloy wire remains stable under extreme temperatures typically found in electrolysis systems, making it ideal for high-temperature electrolysis applications.
Superior Mechanical Strength: The wire's high tensile and yield strength provide structural integrity under the mechanical stresses and pressures common in electrolyzers, ensuring continuous operation without failure.
Thermal Stability: Excellent thermal conductivity and resistance to thermal cycling ensure that the wire performs efficiently even during frequent heating and cooling cycles in electrolysis processes.
Customizable Sizes: Available in a variety of diameters and lengths, the wire can be tailored to meet the specific needs of different electrolysis systems, making it versatile and adaptable to various setups.

Applications of 0Cr15Al5 FeCrAl Wire

Water Electrolysis for Hydrogen Production: The wire is crucial for water electrolysis, where it facilitates the production of hydrogen by splitting water into hydrogen and oxygen, offering superior durability in aggressive electrolytes.
Alkaline Electrolysis: In alkaline electrolyzers, the wire withstands highly alkaline electrolytes, providing excellent corrosion resistance and ensuring longer operational life.
High-Temperature Electrolysis: The wire is well-suited for high-temperature electrolysis applications, capable of maintaining high performance even in elevated temperatures and intense reaction environments.
Fuel Cells and Energy Storage Systems: The wire is also employed in fuel cell applications and energy storage technologies, where its high resistance to corrosion and thermal stability contribute to efficient performance of electrochemical reactions.
Hydrogen Production R&D: Researchers involved in advancing hydrogen generation technologies depend on the wire to test and optimize electrolysis systems for improved hydrogen efficiency and sustainability.

Industry Trends and Applications

The hydrogen economy is growing rapidly as a critical element in the global push for renewable energy solutions. Electrolysis plays a central role in green hydrogen production, especially as the world moves toward decarbonizing industries such as transportation, power generation, and chemical manufacturing. The demand for green hydrogen is expected to rise significantly in the coming decades, driven by efforts to meet sustainability targets and reduce carbon emissions.

As hydrogen production technologies continue to evolve, electrolysis systems need high-performance materials that can withstand extreme operational conditions. The 0Cr15Al5 FeCrAl Wire is perfectly positioned to meet these demands, offering a reliable and durable solution for efficient and cost-effective hydrogen production.

The growing adoption of hydrogen as a clean fuel source in industries such as automotive and energy storage is further driving the need for efficient electrolysis systems. The wire is an essential component in the development of these systems, contributing to the creation of a sustainable hydrogen economy.

Why Choose 0Cr15Al5 FeCrAl Wire?

Enhanced Durability: Designed to withstand harsh conditions of electrolysis systems, offering superior resistance to oxidation, corrosion, and high temperatures for longer lifespan and reduced maintenance.
Increased Hydrogen Production Efficiency: Provides consistent performance in demanding environments, ensuring hydrogen generation is more efficient while minimizing operational downtime.
Adaptable to Different Electrolysis Systems: Available in various sizes and customizable to fit different electrolysis setups, making it versatile for a range of applications.
Cost-Effective Solution: Long-term cost savings due to the wire's longevity and reduced maintenance requirements make it a cost-effective investment for hydrogen production.
Contributing to Sustainable Energy: Enables efficient green hydrogen production, helping advance the global transition to renewable, low-carbon energy solutions.

FAQs

What is 0Cr15Al5 FeCrAl Wire made of?

The wire is made of a high-performance alloy consisting of iron (Fe), chromium (Cr), and aluminum (Al), providing excellent resistance to corrosion and high temperatures.

How does the alloy wire perform in electrolysis systems?

The wire excels in electrolysis systems by resisting corrosion from both alkaline and acidic electrolytes, ensuring long-term performance in hydrogen production processes.

Can the alloy wire be used in high-temperature electrolysis?

Yes, with a melting point of 1,420°C, the wire is ideal for high-temperature electrolysis applications, providing stable and reliable performance.

How does the alloy wire improve hydrogen production?

The wire's corrosion resistance and high mechanical strength ensure consistent performance, increasing hydrogen production efficiency and reducing system downtime.

Is the wire customizable for different applications?

Yes, the wire is available in a variety of sizes and can be tailored to meet the unique needs of different electrolysis systems, ensuring compatibility with a wide range of setups.

What industries use 0Cr15Al5 FeCrAl Wire?

It is used in hydrogen production, fuel cell technologies, energy storage, various electrolysis systems, and research and development for hydrogen generation technologies.

How does the wire contribute to sustainability?

By enhancing the efficiency and longevity of electrolysis systems, the wire helps reduce the carbon footprint of hydrogen production, contributing to a greener, more sustainable energy future.

What is the lifespan of the wire in electrolysis systems?

The wire's exceptional corrosion resistance and high thermal stability ensure a long lifespan, with fewer replacements required, reducing the total cost of ownership in electrolysis systems.
